02–TX150S2–136 July 2004 U41057-J19-Z146-1-76
Conversion of the housing model Removal/installation routines
Ê Prise up the flange on the left housing side carefully with a screws driver and
push the right side cover and the top cover slightly to the rear (arrow).
Ê Take out the right side cover and the top cover sidewards (this part is no
longer needed for the rack model).
Ê Lay the server on a flat surface with the uncovered side facing upwards.
This step has to be carried out by two people as the server may
weight up to 28 kg.
!
