CS875-575-375-275-175 Installers Manual with CS5500 keypad B.10.3
10.2.3 Enrolling the CS320 auxiliary power module
1. Set DIP switches 1-3 to the correct address.
2. Select Enrol Modules>Enrol and press OK. to enrol the CS320 auxiliary power module. The enrolling
process takes about 12 seconds. User codes are not accepted during the enrolling process.
10.3 Programming the CS320 auxiliary power module
You must enroll and default the CS320 power module before you begin to program the system. For more information
on enrolling and defaulting, see Enrolling the CS320 auxiliary power module above and chapter B-1 Enrolling
modules. To program the CS320 power module, select Installer Menu>CS320 Power Modules.
10.3.1 Configuring outputs
You can specify events and partitions that can activate a particular output. The outputs are triggered based on different
events. The events are grouped in the programming tree. A full list of all possible selectable events can be found in
Table 10-3: CS320 power module output events. You can also assign a defined attribute to the output. The following
example enables user code 1 to reset the timer on output 1, power module 84 when an autotest event occurs.
1. Navigate with the µ¶ keys to CS320 Power Modules>Power Module 84>Outputs and press OK.
2. Scroll to Output 1>Event>Tests>Automatic Test and press OK.
3. The keypad beeps once to accept the change and returns to Tests.
4. Scroll to Attributes>Code Stops Timer>Yes and press OK.
5. The keypad beeps once to accept the change and returns to Code Stops Timer.
6. Navigate with the µ¶ keys to Users>(1) User 1>Outputs> and press OK.
7. Press the relevant keys to select output 1 only and press OK.
8. The keypad beeps once to accept the change and returns to Outputs.
T
ime Unit
Time
Partitions
OutputsPower Module 84
Feature Select Mains Delay Time
Battery Test
Battery Test Time
Reports
1 (<Event>) Event Alarms
Arm/Disarm
Communications
Keypads
Sirens
Tamper/Trouble
Tests
Miscellaneous
Attributes
Latched
Code Stops Timer
Inverted
Disable on Listen-in
Report Mains Fault Always
Low Battery
Siren Tamper/Trouble
Users (1) User 1 Outputs
10.1
10.1.1
10.1.2
10.1.3
10.1.4
10.1.5
10.1.6
10.1.1.1
10.1.2.1
10.1.3.1
10.1.3.3
10.1.3.2
10.1.3.4
10.1.1.1.1
10.1.1.1.2
10.1.1.1.3
10.1.1.1.4
10.1.1.1.5
10.1.2.1.1
10.1.3.4.1
10.1.3.4.2
10.1.3.4.3
10.1.1.1.1.1
10.1.1.1.1.8
10.1.1.1.1.7
10.1.1.1.1.6
10.1.1.1.1.5
10.1.1.1.1.4
10.1.1.1.1.3
10.1.1.1.1.2
10.1.1.1.5.1
10.1.1.1.5.4
10.1.1.1.5.3
10.1.1.1.5.2
Power Modules 85 - 91
Same as above
Outputs 2 - 3
Same as above
Users 2 - 99
Same as above
If more than 10 users,
users are first displayed in
groups of 10 and then
displayed as above.
Model
Version
Default Settings
