CS875-575-375-275-175 Installers Manual with CS5500 keypad
B.13.13
13.5 T
echnical sp
ecifications
Power supply specifications
Power supply voltage
12V
±
2%
Consumption - Standby
30 mA at 12V
±
2%
Consumption – Maximum via battery leads
2A at 12V
±
2%
General feature specifications
PCB Size
Dimensions (width x height x depth)
97x102x24 mm
Environmental
Operating temperature
+0° C to + 49 °C
Humidity
Max 93%
Shipping Weight
1
15 g
163
165
Table of Contents
Default Chapter
1
Alarm System
1
Table of Contents
3
Section a
8
Installing and Programming a Basic System
8
Introducing the Csx75 System
9
Getting Started
9
Welcome
9
Default Country Codes
9
Keypads
9
CS5500 Keypad
9
Other LCD and LED Keypads
11
Designing the Csx75 System
12
System Versions
12
Parts of the System
13
Installation Guidelines
18
Mains Power Connection
18
Mounting
18
Cabling
18
Shielded and Unshielded Cable
18
Twisted and Untwisted Cable
18
Wiring Guidelines
18
Defaulting the Panel
19
Using the DIP Switch Diagrams
19
Installing a Basic System
20
Wiring Zones
20
General
20
Dual Wiring
20
Single Wiring
20
Installing the Control Unit
20
CS575M/CS875M (Large Metal Housing
21
CS275/CS375/CS575/CS875 (Polycarbonate Housing
23
CS175M/CS275M/CS375M/CS575SM (Small Metal Housing
25
Installing the Keypad
27
Wiring the Keypad
27
Wiring Several Keypads Together
28
Wiring Sounders
30
Wiring a Sounder with EOL Protection
30
Wiring Fire Detectors
32
4-Wire Fire Detector (CS275-375-575-875
33
4-Wire Fire Detector (CS175
34
Wiring the Outputs
35
Control Unit Wiring Diagrams
36
Cs175
36
Cs275
37
CS375, CS575 and CS875
38
Programming the System
40
Powering up the System
40
Entering Programming Mode
40
Changing the User Interface Language
40
Navigating the Menus
40
Command Menu
40
Selecting a Menu Option
41
Changing a Menu Option
41
Changing Selection List Entries
41
Changing Binary Entries
41
Changing Numeric Entries
41
Changing Phone Numbers and Phone Prefixes
42
Exiting the Menu System
42
Editing Text
42
Overview
42
Example
43
Word Library
43
Installer Message
44
Setting up a Communicator
45
Reporting
45
Reporting to One Phone Number
45
Backup Reporting
45
Dual Reporting
46
Split Reporting
46
Section B
48
Installing and Programming the Modules
48
Enrolling Modules
49
Enrolling the System Modules
49
Defaulting the Modules
49
Glossary
49
Programming the Control Panel
50
Overview
50
Programming Inputs
50
Defining a Zone
51
Copying Zone Settings
51
Editing a Zone Type
52
Setting Swinger Shutdown
52
Programming Outputs
53
Configuring an Output
53
Configuring the Internal Siren
54
Programming the Keypad Sounder
55
Assigning Codes
55
Setting up the Installer Code
55
Setting Communication Options
56
Defining Communication with a Central Station
57
Defining Communication with Upload/Download Software
57
Configuring the System Autotest
57
Enabling Reporting
58
Configuring Partitions
58
Setting Timers
58
Configuring a Partition
59
Configuring the System
59
Setting Timers
60
Configuring System Features
60
Setting Arm Schedules
60
Setting up Schedules
60
Programming the System to Work with a Home Automation System
61
Enabling Broadcasts
62
Enabling Commands and Requests
62
Glossary
63
Technical Specifications
82
Programming the Current Keypads
84
Overview
84
Configuring Keypad Features
84
Multi-Area Mode
85
Assigning X-10 Devices
85
Copying Keypad Settings
85
Configuring Keypad Text
85
Glossary
86
Setting the Keypad Partition and Keypad Number
86
Technical Specifications
89
CS5006 LED Keypad
89
CS5XX8 LED Keypad, Where XX Is the Country Code
89
CS5500 Menu Driven Keypad
90
Keyswitch Zones
90
Setting up the RF Receivers
92
Overview
92
Types of Receivers
92
Installing an RF433 Mhz Receiver
93
Wiring an RF433 Mhz Receiver
93
Setting the RF433 Mhz Receiver DIP Switches
93
RF433 Mhz Receiver Status Conditions
94
Installing an RF868 Mhz Receiver
95
Wiring an RF868 Mhz Receiver
95
Setting the RF868 Mhz Receiver DIP Switches
95
RF868 Mhz Receiver Status Conditions
96
Programming the RF System
97
Defaulting the Wireless Modules
97
Programming the Wireless Detectors
97
Configuring Receiver Features
98
Setting Supervision Windows
98
Testing Wireless Sensors
99
RF433 Mhz System
99
RF868 Mhz System
99
Deleting Sensors
99
Glossary
100
Technical Specifications
102
RF433 Receivers: Rx8I4-Pcb, Rx16I4-Pcb, Rx48I4-Pcb
102
RF868 Receivers: Rx8W8-Pcb, Rx16W8-Pcb, Rx32W8-Pcb
102
Empty Housing RXWEH00 (868 Mhz) and RXIEH00 (433 Mhz
102
Setting up the CS208H / CS208 / CS216
103
Overview
103
CS208 / CS216 Input Expander
103
Installing the CS208 / CS216 Input Expander
103
Setting the DIP Switches
103
Wiring the CS208 / CS216 Input Expander
105
CS208H Input Expander
106
Installing the CS208H Input Expander
106
CS208H Input Expander Board
106
Setting the DIP Switches
107
Wiring the CS208H Input Expander
108
Programming the CS208H / CS208 / CS216 Input Expander
108
Glossary
109
Setting up the CS507
110
Setting the DIP Switches
111
Wiring the CS507 Output Expander
111
7 Setting up the CS507
111
Programming the CS507 Output Expander
113
Setting up Schedules
115
Configuring an Output
115
Configuring Users
115
Glossary
116
Technical Specifications
118
Setting up the CS586
119
Overview
119
Connecting the CS586 Direct Connect Module
119
Connecting the CS586 to a PC
119
Connecting the CS586 to a PC and a Panel
120
Connecting the CS586 to a Panel
120
Programming the CS586 Direct Connect Module
120
Enabling Memory Transfer Using the CS5500 Keypad
121
Enabling Memory Transfer Using Udx75 Software
121
Glossary
122
Technical Specifications
122
Setting up the CS534
123
Overview
123
Installing the CS534 Listen-In Module
123
Wiring the CS534 Listen-In Module
124
General Operating Instructions
124
Control Levels
125
Tones
126
Programming the CS534 Listen-In Module
127
Configuring Listen-In Options
127
Programming Timers
127
Setting Volume Levels
127
Glossary
128
Technical Specifications
130
Setting up the CS320
131
Overview
131
Installing the CS320 Auxiliary Power Module
131
Wiring the CS320 Auxiliary Power Module
132
Setting the DIP Switches
132
Enrolling the CS320 Auxiliary Power Module
133
Programming the CS320 Auxiliary Power Module
133
Configuring Outputs
133
Configuring Features
134
Glossary
135
Technical Specifications
137
Setting up the CS535
138
Overview
138
Installing the CS535 Voice Module
138
Programming the CS535 Voice Module
139
Configuring the Control Panel for Voice Reporting
139
Recording Voice Messages
139
Playing Back Messages
140
Configuring Handshake and Kiss off
140
Glossary
141
Technical Specifications
142
Setting up the CS1700
143
Overview
143
Installing the CS1700 Proximity Reader
143
Wiring the CS1700 Proximity Reader
144
Enrolling the CS1700 Proximity Reader
144
Programming the CS1700 Proximity Reader
145
Programming Badge Functions
145
Configuring X-10 Functions
146
Adding and Deleting Cards
146
Glossary
148
Technical Specifications
151
Setting up the CS7002
152
Overview
152
Installing the CS7002 GPRS Module
153
Enrol the SIM Card on the GSM Network
153
Inserting the SIM Card
154
Wiring the CS7002 GPRS Module
154
Reporting Leds
154
Programming the CS7002 GPRS Module
155
Testing the RSSI Value
155
Reporting
156
Using Upload/Download
157
Glossary
158
Technical Specifications
164
Reserved
165
Setting up the CS7050
166
Overview
166
Installing the CS7050 TCP/IP Module
166
Wiring the CS7050 TCP/IP Module
167
LED Indicators
167
Programming the CS7050 TCP/IP Module
168
Configuring TCP/IP Reporting
169
Configuring Email Reporting
169
Configuring Reporting Options
170
Configuring Upload/Download
170
Glossary
172
Technical Specifications
176
Setting up the CS7501
177
Overview
177
Installing the CS7501 ISDN Dialler
177
LED Indicators
178
Mounting the CS7501 ISDN Dialler
178
Wiring the Battery Leads
182
Programming the CS7501 ISDN Dialler
183
Configuring Phone Reporting
183
Configuring AL2 Supervised ISDN Connection
184
Uploading and Downloading
184
Glossary
185
Technical Specifications
189
Reading the Event Log
190
Overview
190
Event Log Events
191
Glossary
193
Programming with the Udx75 Software
195
Other Methods of Programming
195
Connecting the Panel to the Computer
195
Connecting Using a Serial Port
195
Connecting Using a Modem
195
Programming with Upload/Download Software
196
Programming Tasks
197
Section C
200
Reference
200
Appendices
200
Appendix 1: Reporting Fixed Codes in Contact ID or SIA
201
Appendix 2: Overview of Module Numbers
202
CS1700 Door Swipe Module
202
Keypads
202
Appendix 3: Communicator Formats
203
Appendix 4: Service Messages
203
Appendix 5: Tasks Summary
206
Appendix 6: Word Library Words
206
