5.4 Programming the RF system
5.4.1 Defaulting the wireless modules
You must enroll and default each RF receiver before you begin programming the system.
You must default each module before you start programming it.
1. Navigate with the µ¶ keys to RF Receivers and press OK.
2. Select the relevant module bus ID and press OK. In this case select RF Receiver 32 and press OK.
3. Select Default Settings and press OK.
4. A confirmation message is displayed. Press OK to accept the default settings.
5. The keypad sounder beeps once to confirm the reset.
5.4.2 Programming the wireless detectors
1. Navigate with the µ¶ keys to RF Receivers and press OK.
2. Select the relevant module bus ID and press OK. In this case select RF Receiver 32 and press OK.
3. Scroll to Start Zone and press OK.
4. Enter the starting zone of the receiver. In this case, enter zone 9 to set zone 9 as the starting zone for receiver
32.
5. Scroll to Learn-in Mode and press OK.
6. To learn-in more than one device, scroll to Sequential Programming, select Yes and press OK.
Model
Version
Default Settings
Internal Reed
External Contact
Receiver Features
Tamper
Jam Detection
Keyfob User ID
Keyfob Low Battery Reports*
Antenna Tamper**
Box Tamper**
Inputs
Enabled
Supervised
Fire Supervision
Keyfob
Keyfob Funct 1
Keyfob Funct 2
Partitions
Door/Window*
Smoke*
Sensor 1
5.1.3
5.1.4
5.1.3.1
5.1.4.1
5.1.4.2
5.1.4.3
5.1.4.4
5.1.3.1.1
5.1.3.1.2
5.1.3.1.3
5.1.3.1.4
5.1.3.1.5
5.1.3.1.6
5.1.3.1.4.1
5.1.3.1.4.3
5.1.3.1.4.2
5.1.3.1.5.1
5.1.3.1.5.2
5.1.3.1.6.1
RSSI Check Zone*
RSSI Value*
Last Round Count**
Supervision
Normal Window
Short Window
Fire Window
RF Signal
5.1.5
5.1.6
5.1.7
5.1.8
5.1.9
5.1.4.5
5.1.5.1
5.1.5.2
5.1.5.3
5.1.6.1
5.1.6.2
5.1.6.3
Sensors 2 - 168
Same as above
Range of sensors depends
on the number of sensors
and the start zone
number.
*Disabled for 868 Mhz
receivers
*Disabled for 868 Mhz
receivers
* Disabled for 433 Mhz receivers
**Disabled for 868 Mhz receivers
* Disabled for 433 Mhz receivers
** Disabled for 868 Mhz receivers
Delete
5.1.3.1.7
Start Learning
Start ZoneRF Receiver 32
Learn-in Mode
5.1 5.1.1
5.1.2 5.1.2.1
5.1.2.2
RF Receivers 33 - 39
Same as above
(1) Zone 1
Sequential Programming
5.1.2.1.1
