GE Security CS575 User Manual

CS875-575-375-275-175 Installers Manual with CS5500 keypad B.10.7
10.5 Technical specifications
Mains power specifications
Mains Input Voltage (25VA Transfo) 230V ~ - 50Hz ± 10% - 25VA
Mains Input Voltage (40VA Transfo) 230V ~ - 50Hz ± 10% - 40VA
Current consumption at 230V~ (25 VA) 0.108 A
Current consumption at 230V~ (40 VA) 0.173 A
Main board supply voltage 16.5 V ~ typical
Power supply specifications
Power supply voltage 13.8V ± 2%
Consumption - Standby 40 mA at 13.8V ± 2%
Consumption – Maximum 110 mA at 13.8V ± 2%
General feature specifications
PCB Size Dimensions (width x height x depth) 161x108x28 mm
Housing Size Dimensions (width x height x depth)
DHX75PB 380x260x120 mm
DHX75PBM 450x300x90 mm
Environmental Operating temperature +0° C to + 40 °C
Humidity Max 93% non condensing
Shipping Weight 146g

GE Security CS575 Specifications

General

Brand	GE Security
Model	CS575
Category	Security System
Language	English
