CS875-575-375-275-175 Installers Manual with CS5500 keypad C.1.3
1.3 Appendix 3: Communicator formats
One of several communicator formats can be used to transmit to the receiver connected to phone number 1.
Consult the instructions for your central station receiver to determine which format is compatible. Table 1-4:
Communicator formats lists the selectable communication formats.
< 1.If you require a format other than those listed, set the override options in Communications>Format
Override to build the appropriate format. In addition, select Format Override in Communications>Central
Station>Phone Numbers>Phone Number n>Protocol.
< 2.The voice dialer protocol does not generate an FTC (failure to communicate).
1.4 Appendix 4: Service messages
The keypad displays service messages as a result of manual and automatic tests. Table 1-5: Service messages
lists each message and outlines the action you should take to resolve the problem. When the keypad beeps due to
a fault condition, press the # key to view the fault condition information.
Table 1-4: Communicator formats
# Format Description
1 Contact ID
2SIA
3 SIA with area modifiers
4 Voice dialler with handshake and DTMF kiss-off
5 Reserved
6 4+2 with 1400/1900 double round parity
7 4+2 with 1400/1900 Checksum parity
8 4+2 with 2300/1800 double round parity
9 4+2 with 2300/1800 Checksum parity
10 Fast format 8 channel
11 Fast format 16 channel
12 Siren tone
13 Reserved
14 Reserved
15 Format over-rides (build your own format)
16 Reserved
17 200 Baud FSK (France Only)
18 200 Baud FSK Reversed (France Only)
19 XSIA
20 XSIA with area modifier
21- 255 Reserved
Table 1-5: Service messages
Message Definition Action
Control
Box Tamper
There has been interference with the control panel
casing.
Ensure that the casing is mounted correctly on a flat surface and
is not damaged. If there is no damage, close the casing securely.
