CS875-575-375-275-175 Installers Manual with CS5500 keypadB.10.4
10.3.2 Configuring features
You can configure testing and reporting features for the CS320 power module. The following example enables a battery
test which lasts for 60 minutes and sends a report to the central station when a low battery condition occurs.
1. Navigate with the µ¶ keys to CS320 Power Modules>Power Module 84>Feature Select and press OK.
2. Scroll to Battery Test>Enabled and press OK.
3. The keypad beeps once to accept the change and returns to Battery Test.
4. Scroll to Battery Test Time and press OK.
5. Select 60 min. and press OK.
6. The keypad beeps once to confirm the change and returns to Battery Test Time.
7. Scroll to Reports>Low Battery>Yes and press OK.
8. The keypad beeps once to accept the change and returns to Low Battery.
Table 10-3: CS320 power module output events
# Event # Event # Event
Alarms Arm/disarm Misc
17 Alarm Memory 21 Armed 32 Code Entry
Tests 22 Disarmed 7 Program Mode
3 Dyn Battery Test 23 Ready to Arm 0 Always On
Tampers 18 Entry Keypads
25 Fire LED 19 Exit 29 Keypad Fire
11 Smoke Det Reset 20 Entry or Exit 30 Keypad Medical
8 Over-current 24 Not Ready to Arm 31 Keypad Panic
9 Box Tamper
Sirens 28 Keypad Beeping
10 Siren Tamper 12 Burglary Siren 27 Chime
26 Fire Trouble 13 Fire Siren
Communications
1 Mains Failure 14 Any Siren 4 Listen-in
2 Low Battery 15 Fire Sir Steady 5 Line Seizure
16 Any Sir Temporal 6 Phone Line Fault
