GE 269Plus

GE Power Management 269Plus Motor Management Relay 9- 1
9 COMMISSIONING 269PLUS COMMISSIONING SUMMARY
9
269 MOTOR MANAGEMENT RELAY 9 COMMISSIONING 9.1 269PLUS COMMISSIONING SUMMARY
Table 9–1: COMMISSIONING TABLE (Sheet 1 of 7)
SETPOINTS VALUES
PAGE 1: MOTOR AMPS SETPOINTS
PHASE CT SECONDARY
PHASE CT PRIMARY
MOTOR FULL LOAD CURRENT A
O/L PICKUP LEVEL %
ACCLERATION TIME sec.
STARTS/HOUR
UNBALANCE ALARM LEVEL %
UNBALANCE ALARM DELAY sec.
UNBALANCE TRIP LEVEL %
UNBALANCE TRIP DELAY sec.
GROUND FAULT CT RATIO :5?
GROUND FAULT CT PRIMARY
1
GROUND FAULT ALARM LEVEL A
GROUND FAULT ALARM DELAY sec.
GROUND FAULT TRIP LEVEL A
GROUND FAULT TRIP DELAY sec.
UNDERCURRENT ALARM LEVEL A
UNDERCURRENT ALARM DELAY sec.
UNDERCURRENT TRIP LEVEL A
UNDERCURRENT TRIP DELAY sec.
MECHANICAL JAM ALARM x FLC
MECHANICAL JAM ALARM DELAY sec.
RAPID TRIP / MECHNICAL JAM LEVEL x FLC
RAPID TRIP DELAY sec.
SHORT CIRCUIT TRIP LEVEL x FLC
SHORT CIRCUIT TRIP DELAY sec.
IMMEDIATE OVERLOAD x FLC
1
Not seen if ratio is 2000:1
2
If NO, all RTD setpoints on all pages are not visible
3
Not seen if DEFEAT RTD IN PUT is YES
4
Not seen if DEFEAT U/B INPUT is YES
5
Only seen if 269Plus is a drawout relay
6
Not seen if BLOCK PF PROTECTION ON START is YES
7
Not seen if BLOCK PF PROTECTION ON START is NO
PAGE 2: RTD SETPOINTS
RTD SENSOR TYPE (not a setpoint)
ANY RTDs CONECTED?
2
RTD MESSAGE DISPLAY
#OFSTATORRTDsUSED
RTD/STATOR 1 ALARM LEVEL °C/°F
RTD/STATOR 1 HIGH ALARM LEVEL °C/°F
RTD/STATOR 1 TRIP LEVEL °C/°F
RTD/STATOR 2 ALARM LEVEL °C/°F
RTD/STATOR 2 HIGH ALARM LEVEL °C/°F
RTD/STATOR 2 TRIP LEVEL °C/°F
RTD/STATOR 3 ALARM LEVEL °C/°F
RTD/STATOR 3 HIGH ALARM LEVEL °C/°F
RTD/STATOR 3 TRIP LEVEL °C/°F
RTD/STATOR 4 ALARM LEVEL °C/°F
RTD/STATOR 4 HIGH ALARM LEVEL °C/°F
RTD/STATOR 4 TRIP LEVEL °C/°F
RTD/STATOR 5 ALARM LEVEL °C/°F
RTD/STATOR 5 HIGH ALARM LEVEL °C/°F
RTD/STATOR 5 TRIP LEVEL °C/°F
RTD/STATOR 6 ALARM LEVEL °C/°F
RTD/STATOR 6 HIGH ALARM LEVEL °C/°F
RTD/STATOR 6 TRIP LEVEL °C/°F
RTD 7 ALARM LEVEL °C/°F
RTD 7 TRIP LEVEL °C/°F
RTD 8 ALARM LEVEL °C/°F
RTD 8 TRIP LEVEL °C/°F
RTD 9 ALARM LEVEL °C/°F
Table 9–1: COMMISSIONING TABLE (Sheet 2 of 7)
SETPOINTS VALUES
1
Not seen if ratio is 2000:1
2
If NO, all RTD setpoints on all pages are not visible
3
Not seen if DEFEAT R TD INPUT is YES
4
Not seen if DEFEAT U/B INPUT is YES
5
Only seen if 269Plus is a drawout relay
6
Not seen if BLOCK PF PROTECTION ON START is YES
7
Not seen if BLOCK PF PROTECTION ON START is NO
