9.8 Using Manual instructions
It is possible to manually interact with an ongoing method using Manual instructions.
ActionStep
In the System Control module:1
•
On the Manual menu. click Execute Manual Instructions
or
•
use the shortcut Ctrl +M.
Result: The Manual instructions dialog box opens.
In the Manual instructions dialog box:2
•
Click the + symbol to show the instructions for the instruction group that
you want to modify.
•
Select the instruction that you want to modify.
•
Enter the new values for the instruction.
To execute several instructions at the same breakpoint, select and edit an
instruction and click Insert. Repeat for several instructions.
3
To update parameter fields during method run, select the Auto update
checkbox.
4
To perform the instructions, click Execute.5
All available manual instructions are described in the following subsections.
ÄKTA avant User Manual 29035184 AE 475
9 Reference information
9.8 Using Manual instructions
