Rail extension
The Rail extension rod can be used to attach accessories, for example column holders
or a Multi-purpose holder. The rod has extra rails on both sides. Push the button of the
rod to attach it to a holder rail.
1 2
FunctionPart
Button1
Extension rod2
Multi-purpose holder
The Multi-purpose holder can be used to attach accessories, for example a Loop holder
or a cassette. Attach the holder to a holder rail.
1 2
3 4 3
ÄKTA avant User Manual 29035184 AE 51
2 The ÄKTA avant instrument
2.6 Accessories
2.6.2 Tubing holders and other accessories
