DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
3 - 10 Section 3-3 - Receiving and unpacking the equipment
13.
From the back of the pallet, unhook the
strap (will be called out) from the other
end of the LOGIQ E10.
14.
Attach the wooden ramp to the rear of the
pallet base and fasten the Velcro straps.
15.
Using two people, pull the unit down the
ramp on the back off the pallet.
Note: Remember to pull in the LOGIQ
E10 from the back for safer
transportation.
16.
Check the empty pallet to see if the filter covers came off during shipping.
17.
For future use, store all of the packing materials inside the box.
Table 3-4 Uncrating Instructions (Continued)
Steps Corresponding Graphic

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
