GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 4 Functional Checks 4 - 5
ECG
LOGIQ E10 Basic Service Manual, Direction 5750007-1EN,
Rev. 1. Leakage Current measured at (record the value) and
meets allowable limits. Equipment passed all required checks
and is ready for use.
4-2-7 Probe/Connectors Checks
4-2-7
PW/CW Doppler Mode Checks
use Pencil Probes
10-7-7
Isolated patient lead (source) leakage-
lead to ground
10-7-8
Isolated patient lead (source)
leakage–lead to lead
10-7-9
Isolated patient lead (sink) leakage-
isolation test
4-2-7
ECG Checks
Active ECG:
Utility -> Applications ->
Settings -> ECG -> Show ECG
Tools.
Connect cables. Press Display ECG
Tab on TP. Verify ECG signal
displayed on monitor.
Plug in the ECG cables with nothing
attached so they pick up noise.
Diagnostics
Diagnostics
4-2-7
Shear Wave Elastography (Shear
Elasto) Functional Checks
Power Assistant
4-2-7 Probe/Connectors Checks
Verify Power Assistant Option
functions
Shear Wave
4-2-7 Probe/Connectors Checks
4-2-7
Shear Wave Elastography (Shear
Elasto) Functional Checks
Perform a 4D sweep, if 4D MC was
removed.
V Nav
4-2-7 Probe/Connectors Checks
4-2-7
3D/4D and Volume Navigation
Functional Checks
4-2-7 Basic Measurements
diags
Table 4-2 General System Functional Checks
See:
Section
Functional Check Debrief Script

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
