GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 5 Components and Functions (Theory) 5 - 17
5-7-3 SSD
The SSD (Solid State Drive) is connected to the ECB to further host the C (Windows 10 operating
system and application and utilities) and Z (Software Repository and additional files for Software
Reload) partitions of the HDD. No patient data is stored on the SSD.
Location of the SSD in the LOGIQ E10
Figure 5-3 SSD location

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
