GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 6 Service Adjustments 6 - 9
For complete information, Refer to the appropriate version of the LOGIQ E10 Basic User Manual,
Chapter 3. See: Section 1-5 "Label locations" on page 1-26.
CT
Used for
Luminance
response
Contrast. Confirm that you can detect the
circles within the square grayscale boxes.
Table 6-2 Test Patterns
Test
Pattern
Description Corresponding Graphic

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
