DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 38 Section 8-6 - Replacing Covers and Bumpers
8-6-4 Front Cover replacement
Front Cover removal
The Front Cover is attached to the LOGIQ E10 with tabs at the top, inside of the Cover and slots in the
Top Cover, and four self-clinching studs. Two studs are located above the probe connectors and two
are located at the bottom of the cover.
Table 8-26 Manpower / Time and Tools
Manpower /
Time
Tools / PPE
One person /
15 minutes
Refer to: 8-2-5 "Tools needed for servicing the LOGIQ E10" on page 8-6 /
8-2-6 "PPE Required During Service" on page 8-6.
Table 8-27 Preparations and Preparation Links
Preparations - you must perform the following steps
1. Power down the system.
2. Disconnect the mains power cable from the wall outlet and all Probes and External I/O Cabling.
3. Remove the Side Covers.
Preparation Links (if you need more information):
• 4-2-4 "Power SHUT DOWN" on page 4-9.
• 8-6-3 "Side Cover(s)/Side Air Intake (Filter) inspection / replacement" on page 8-33.
Table 8-28 Front Cover removal
Steps
Corresponding Graphic
1.
Raise the Upper OP to the highest position.
With both hands at the lower sides of the
cover, gently and evenly, pull the cover out
and tilt up.
Set cover in a safe place.
