DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 154 Section 8-7 - Replacing Top Console Parts
Upper OP Frame installation
Table 8-178 Upper OP Frame installation
Steps Corresponding Graphic
1. Position the Upper OP Frame onto the Lower Frame.
2. Install the Upper Frame with the screws and washers removed.
3. Support the two Frames and remove the temporary screws. Continue to support the Frames to
install the Bulkhead Plate.
Re-install the Bulkhead Bracket Housing (behind the Bulkhead Plate) and install the Plate with
the two 20 mm at the top and the two 25 mm at the bottom. Torque: 4.3 Nm (3.2 lbf-ft).
4. Re-install the:
• Main Cable to the Lower OP,
• Grounding Strap Clamp. Torque: 4.3 Nm (3.2 lbf-ft).
• P-clamp screw and lock washer, using a #1 Phillips screwdriver.
• Bulkhead Board,
• Lower OP and Upper OP,
• Monitor Adapter, Monitor Arm and Monitor,
• Re-install all Covers removed.
To Next Page
