DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 193
Preparation Links (if you need more information):
• 4-2-4 "Power SHUT DOWN" on page 4-9.
• Section 8-6 "Replacing Covers and Bumpers" on page 8-29.
• 8-7-3 "Main Monitor Arm assembly replacement" on page 8-91.
• 8-7-4 "Main Monitor Arm Assembly Adapter replacement" on page 8-99.
• 8-7-9 "Upper OP (Operator Panel)/Touch Panel Assembly replacement" on page 8-117.
• 8-7-10 "Lower OP (Operator Panel) replacement" on page 8-122.
• 8-7-11 "Bulkhead Board replacement" on page 8-127.
• 8-7-12 "Bulkhead, Plate, Extended replacement" on page 8-133.
• 8-7-17 "Upper OP Frame Assembly replacement" on page 8-152.
• 8-7-18 "Lower OP Frame Assembly replacement" on page 8-156.
Figure 8-4 XY-Mechanism
Table 8-224 Preparations and Preparation Links
Preparations - you must perform the following steps
To Next Page
