DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 273
ECB removal
Table 8-302 ECB removal
Steps Corresponding Graphic
1.
Remove all cabling to the ECB.
2.
Remove the two screws that secure the
ECB to the Card Cage.
