DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 279
Preparation Links (if you need more information):
•
4-2-4 "Power SHUT DOWN" on page 4-9.
• 8-6-3 "Side Cover(s)/Side Air Intake (Filter) inspection / replacement" on page 8-33.
• 8-11-3 "Front End Card Cage Cover replacement" on page 8-255.
• 8-11-8 "ECB replacement" on page 8-272.
Figure 8-9 Small, close quarters ratchet set Alternate
Table 8-307 Preparations and Preparation Links
Preparations - you must perform the following steps


A
B

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
