DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 305
11.
Locate the CW Option cable, on the front of
the Card Cage.
Pull straight off to disconnect from the
Backplane.
Table 8-329 Backplane removal
Steps Corresponding Graphic
