8 - 416 Section 8-16 - Options replacement
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws that you removed earlier have been installed.
2.) Connect cables and probes removed earlier.
3.) Power up the system to verify that it operates as intended.
Functional Checks
Perform the following functional tests to confirm the system is operational before returning the system
to the customer.
Table 8-411 CW Option replacement Functional Checks
See
Section
Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, (latest version). Leakage
Current measured at (record the value) and
meets allowable limits. Equipment passed all
required tests and is ready for use.
4-2-7 B-Mode Checks
4-2-7 System CFM and PWD Checks
4-2-7
PW/CW Doppler Mode Checks
use pencil probes
4-2-7 Probe/Connectors Checks
10-8-3 Grounding continuity
10-8-4 Chassis Leakage Current Test
Perform a CW scan with P2D, P6D,
M5S-D probes (plug in and scan)
4-2-4 Power SHUT DOWN
