DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 424 Section 8-16 - Options replacement
Power Assistant Option replacement
For location of the Option in the LOGIQ E10, see: Table 8-401 "LOGIQ E10 Option Location" on page
8-408.
Table 8-419 Power Assistant Option replacement
Steps Corresponding Graphic
1.
The Power Assistant Option connects
directly to the Backplane.
Remove the two flange nuts securing the
Battery Cover, using a 7 mm driver.
Remove the Cover.
NOTE: It is not necessary to remove the
Battery Bracket.

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
