DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
2 - 4 Section 2-2 - General LOGIQ E10 requirements
2-2-2 Electrical requirements
General requirements
NOTE: GE requires a dedicated power and ground for the proper operation of its ultrasound equipment. This
dedicated power shall originate at the last distribution panel before the LOGIQ E10.
The LOGIQ E10 will function on voltages from 100-240 volts and 50 or 60 Hz. However, if using 220
volt power, then a center tapped power source is required.
Sites with a mains power system with defined neutral and live:
The dedicated line shall consist of one phase, a neutral (not shared with any other circuit), and a full
size ground wire from the distribution panel to the LOGIQ E10 outlet.
Sites with a mains power system without a defined neutral:
The dedicated line shall consist of one phase (two lines), not shared with any other circuit, and a full
size ground wire from the distribution panel to the LOGIQ E10 outlet.
NOTE: Please note that image artifacts can occur, if at any time within the facility, the ground from the
main facility’s incoming power source to the Ultrasound system is only a conduit.
Electrical requirements for LOGIQ E10
In the table below, the electrical specifications for the LOGIQ E10 include monitor and on board
peripherals.
Inrush current
During power on, an inrush circuit prevents the current from increasing above the stated values.
NOTE: These values are estimations.
Table 2-3 Electrical specifications for the LOGIQ E10
PART NUMBER DESCRIPTION VOLTAGE TOLERANCES
POWER
CONSUMPTION FREQUENCY
5935000E10 LOGIQ E10, 100-240 VAC 100-240 VAC +/-10% 0.9 KVA 50/60 Hz
Table 2-4 Inrush current at different mains voltages
VOLTAGE 50 Hz 60 Hz
90 VAC 13 A 12 A
110 VAC 9 A 11 A
220 VAC 5.5 A 6 A
264 VAC 6 A 5 A
