DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
10 - 24 Section 10-7 - Electrical Safety Tests
Isolated lead (sink) leakage test record
Table 10-15 on page 10-24 shows a typical format for recording the isolated patient lead sink leakage
current.
Measurements should be recorded for the full lead combination under each set of test conditions
specified in:
• Table 10-9 on page 10-14
• Table 10-10 on page 10-14 as applicable.
Record all data on the Inspection Certificate.
1.) Connect Safety analyzer to wall AC power outlet.
2.) Plug the equipment under test power cable into the receptacle on the panel of the meter.
3.) Connect the ECG cable to the scanner and the Patient leads to the analyzer.
4.) Select the Lead isolation or main applied function on the meter.
NOTE: Consult the manufacturer’s user manual of the Safety Analyzer.
• Test opening and closing the ground with the scanner on and off as indicated in Table 10-9 or
Table 10-10 as applicable.
NOTE: Consult the manufacturer’s user manual of the Safety Analyzer.
Table 10-15 Typical data format for recording isolated lead (sink) leakage
Unit under test___________________________ Date of test:_____________________
Test Conditions Patient Lead
System Power Grounding/PE RA+LA+LL
On Closed
Off Closed

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
