8-6-9-5 IPP Module Installation Procedure
1.) Attach the new IPP module on the MPB receptical and secure with three screws.
2.) Connect the power connector from the front of the system. Make sure the connector orientation is
correct.
3.) Connect the ground cable.
4.) Install the MPB module.
5.) Install the PSU module.
6.) Install the Battery modules.
7.) Install the MPB Power Door.
8.) Refit the following covers: MPB Front Metal Door, Left side eTower, Right Side eTower, Lower Front
eTower, and RS Probe cover.
9.) Install all accessories.
10.)Turn ON power to the system.
• MPB Module Installation Procedure
• PSU Module Installation Procedure
• Battery Module Installation Procedure
• MPB Door Cover Installation Procedure
• MPB Front Metal Door Installation Procedure
• Right Side eTower Cover Installation Procedure
• Left Side eTower Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• RS Probe Cover Installation Procedure
• Accessories - Replacement Procedures
Perform the checks listed in IPP Module Replacement Procedure on page 8-218
