8-110 Section 8-6 - Mechanical Parts- Replacement Procedures
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-7-1-5 MPB Rear USB Cable Installation Procedure
1.) Connect the MPB to Rear USB Cable to the rear panel connector and tighten the two screws
(previously removed).
2.) Connect the USB cable connector to the MPB J12 connector.
3.) Install the MPB module and tighten the two mounting screws.
4.) Install the PSU module.
5.) Install the battery pack units.
6) Install MPB Front Metal Door.
7.) Refit the following covers: Lower Front eTower, left side eTower, Right side eTower and RS Probe
cover.
8.) Install all accessories.
9.) Turn ON power to the system.
• MPB Module Installation Procedure
• PSU Module Installation Procedure
• Battery Module Installation Procedure
• MPB Front Metal Door Installation Procedure
• Left Side eTower Cover Installation Procedure
• Right Side eTower Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• RS Probe Cover Installation Procedure
• Accessories - Replacement Procedures
Perform the checks listed in MPB Rear USB Cable Replacement Procedure on page 8-218
