12 ADL300 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.20 530 Slot 1 card type ENUM None 0 0 R FVS
2.21 532 Slot 2 card type ENUM None 0 0 R FVS
2.22 534 Slot 3 card type ENUM None 0 0 R FVS
The type of expansion card installed in the relative slot of the drive is displayed.
0 None
257 I/O 1
1281 I/O 2
2305 I/O 3
3841 I/O 4
4865 I/O 5
5377 I/O 6
8 Enc 1
264 Enc 2
520 Enc 3
776 Enc 4
1032 Enc 5
4 Can/Dnet
260 Probus
516 Gdnet
255 Unknown
1544 Enc 4 Dbss
Note! See Appendix to the Quick start guide for further information on the expansion cards.
SLOT 3 indicates the presence of the CAN on the regulation card in versions ADL300-...-C
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.23 536 Slot 1 card S/N UINT32 0 0 0 R FVS
2.24 538 Slot 2 card S/N UINT32 0 0 0 R FVS
2.25 540 Slot 3 card S/N UINT32 0 0 0 R FVS
The serial number of the expansion card installed in the relative slot of the drive is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.26 546 Fw encoder ver.rel UINT16 0 0 0 R FVS
The version and release number of the encoder rmware used in the drive are displayed. On the keypad these are dis-
played in version.release format. When the parameter is read via serial line or eldbus the version is returned in the high
byte and the release in the low byte.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.27 548 Fw encoder type UINT16 0 0 0 R FVS
The type of rmware installed in the encoder is displayed.
