ADL300 • Functions description and parameters list 55
11 - DIGITAL OUTPUTS
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.01 1410 Dig output 1X src LINK 16BIT 1062 0 16384 ERW FVS
11.02 1412 Dig output 2X src LINK 16BIT 3708 0 16384 ERW FVS
11.03 1414 Dig output 3X src LINK 16BIT 3702 0 16384 ERW FVS
11.04 1416 Dig output 4X src LINK 16BIT 3714 0 16384 ERW FVS
11.05 1418 Dig output 5X src LINK 16BIT 1062 0 16384 ERW FVS
11.06 1420 Dig output 6X src LINK 16BIT 3708 0 16384 ERW FVS
11.07 1422 Dig output 7X src LINK 16BIT 3702 0 16384 ERW FVS
11.08 1424 Dig output 8X src LINK 16BIT 3714 0 16384 ERW FVS
The destination associated with the digital input of the expansion card is displayed. The functions that can be associated
with the digital outputs are listed in the “L_DIGSEL1” selection list”.
Note ! The parameters Dig output 5X src ... Dig output 8X src are available only in the ADL300A version with a specific expansion card. See the
ADL300 QS manual.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.09 1430 Dig out 1X inversion BIT 0 0 1 ERW FVS
11.10 1432 Dig out 2X inversion BIT 0 0 1 ERW FVS
11.11 1434 Dig out 3X inversion BIT 0 0 1 ERW FVS
11.12 1436 Dig out 4X inversion BIT 0 0 1 ERW FVS
11.13 1438 Dig out 5X inversion BIT 0 0 1 ERW FVS
11.14 1440 Dig out 6X inversion BIT 0 0 1 ERW FVS
11.15 1442 Dig out 7X inversion BIT 0 0 1 ERW FVS
11.16 1444 Dig out 8X inversion BIT 0 0 1 ERW FVS
Inversion of the logic status of the function associated with the digital output of the expansion card.
0 O
1 On
Note ! The parameters Dig out 5X inversion ... Dig out 8X inversion are available only in the ADL300A version with a specific expansion card. See
the ADL300 QS manual.
