ADL300 • Functions description and parameters list 95
The CiA 417 is an MDPLC application. See the CiA 417 manual for conguration).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.2.2 4004 Fieldbus baudrate ENUM 500k 0 4 ERW FVS
Setting of the communication network speed (Baud Rate)
0 Auto
1 125k
2 250k
3 500k
4 1M
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.2.3 4006 Fieldbus address INT16 2 0 255 ERW FVS
Setting of the node address of the drive when connected to the network.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.2.4 4010 Fieldbus M->S enable ENUM Enable 0 1 ERWZ FVS
Setting of eldbus data updating.
0 Disable
1 Enable
If set to 0, the possibility of sending commands and references from the drive PLC via the eldbus is disabled.
If set to 1 the possibility of sending commands and references from the drive PLC via the eldbus is enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.2.5 4012 Fieldbus alarm mode INT32 0 0 1 ERWZ FVS
Setting of the Opt Bus Fault alarm generation mode.
0 Disable
1 Enable
If set to 0 the alarm is only generated if the communication with the eldbus is lost with the drive enabled..
If set to 1 the alarm is generated when the communication with the eldbus is lost even if the drive is disabled. .
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.2.6 4014 Fieldbus state ENUM Stop 0 2 R FVS
The logic status of the eldbus connection is displayed. The value depends on the type of bus that is used.
0 Stop
1 Pre operational
2 Operational
21.3 - COMMUNICATION/FIELDBUS M2S
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.3.1 4020 Fieldbus M->S1 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.5 4030 Fieldbus M->S2 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.9 4040 Fieldbus M->S3 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.13 4050 Fieldbus M->S4 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.17 4060 Fieldbus M->S5 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.21 4070 Fieldbus M->S6 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.25 4080 Fieldbus M->S7 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.29 4090 Fieldbus M->S8 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.33 4100 Fieldbus M->S9 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.37 4110 Fieldbus M->S10 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.41 4120 Fieldbus M->S11 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.45 4130 Fieldbus M->S12 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.49 4140 Fieldbus M->S13 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.53 4150 Fieldbus M->S14 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.57 4160 Fieldbus M->S15 ipa FBM2SIPA 0 0 20000 ERW FVS
21.3.61 4170 Fieldbus M->S16 ipa FBM2SIPA 0 0 20000 ERW FVS
Setting of the parameter to associate with the bus channel. The default setting is 0, which means channel not active.
If the parameter to be connected is a sorg (source), the channel and parameter can also be associated by modifying the
