ADL300 • Functions description and parameters list 7
B - Parameters and functions description (Expert list)
Legend
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1 - MONITOR
1.1 250 Output current A FLOAT 16/32 0.0 0.0 0.0 R FVS
1.2 252 Output voltage V FLOAT 16/32 0.0 0.0 0.0 R FVS
21.5 - COMMUNICATION/WORD COMP
21.5.1 4400 Word bit0 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.16 4430 Word bit15 src LINK 16BIT 6000 0 16384 ERW FVS
L_DIGSEL1 ( Selection List ) [*]
( Level 1 menu)
( Level 2 menu )
Indexing of the menu and parameter
Parameter identifier
Parameter description
UM: unit of measure
Type of parameter
BIT Boolean, from modbus seen as 16 bits
ENUM Selection list, from modbus seen as 16 bits
FLOAT Real, from modbus seen as 32 bits
INT16 Integer with sign 16 bits, from modbus seen as 16 bits
INT32 Integer with sign 32 bits, from modbus seen as 32 bits
ILINK Selection list, from modbus seen as 16 bits
LINK Selection list, from modbus seen as 16 bits
UINT16 Integer without sign 16 bits, from modbus seen as 16 bits
UINT32 Integer without sign 32 bits, from modbus seen as 32 bits
Format of data exchanged on Fieldbus (16BIT, 32BIT)
Default value
CALCF Value calculated as a number with
floating point
CALCI Value calculated as a whole number
SIZE Value depending on the size of the drive
Minimum value
Maximum value
Accessibility :
E Expert
R Read
S Size (set value depending on the size of the device)
W Write (scrittura)
Z parameters that can be modified ONLY with the drive disabled
Available in regulation mode:
V = V/f Control (open loop) / PM synchronous
S = Vect Flux OL
F = Vect Flux CL (closed loop)
[*]
Selection lists:
The “Sorgente.../Sorg...” format parameters are linked to a
selection list.
The source of the signal that will control the parameter can be
selected from the list indicated.
The lists are indicated in paragraph C of this manual.
