18 ADL300 • Functions description and parameters list
5 - LIFT
Multi speed conguration table:
Through the combination of “MtlSpd S0” (Digital input 4), “MtlSpd S1” (Digital input 5) and “MtlSpd S2” (Digital input 6)
commands, is possible to select Multi speed desired, according to next table:
MtlSpd S2 MtlSpd S1 MtlSpd S0 ACTIVE SPEED
0 0 0 Multispeed 0, PAR 11020
0 0 1 Multispeed 1, PAR 11022
0 1 0 Multispeed 2, PAR 11024
0 1 1 Multispeed 3, PAR 11026
1 0 0 Multispeed 4, PAR 11028
1 0 1 Multispeed 5, PAR 11030
1 1 0 Multispeed 6, PAR 11032
1 1 1 Multispeed 7, PAR 11034
5.1 – SPEED
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.1.1 11002 Travel units sel Hz ENUM 0 0 2 RW FVS
Selection of the unit of measure for speed references.
0 Hz (output frequency)
1 m/s (cabin speed and depends on the mechanical constant)
2 Rpm (speed of the motor shaft)
3 USCS (US units: fpm, ft/s
2
, ft/s
3
)
When the unit of measure is modied the conversion constants are re-calculated, the units of measure are changed in the
parameter list and the multispeed values are converted into the new unit of measure (the result may contain approxima-
tions due to the conversion calculations).
A variable representing the speed of the cabin in m/s (fpm) is always available (PAR 12210).
There are xed units of measure for the acceleration and deceleration parameters m/s² (ft/s
2
), and for jerks m/s³ (ft/s
3
).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.1.2 11020 Multi speed 0 Hz FLOAT 5.00 -10000 10000 RW FVS
Setting of the multispeed 0 value. Can be selected via digital input, eldbus, etc.
The selected value is the reference for the S-shaped lift ramp.
This setting is taken as the default low speed value.
Change in the Multi-speed 0 value is only acquired the next time the drive is rebooted.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.1.3 11022 Multi speed 1 Hz FLOAT 50.00 -10000 10000 RW FVS
Setting of the multispeed 1 value. Can be selected via digital input, eldbus, etc.
The selected value is the reference for the S-shaped lift ramp.
This setting is taken as the default high speed value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.1.4 11024 Multi speed 2 Hz FLOAT 20.00 -10000 10000 RW FVS
Setting of the multispeed 2 value. Can be selected via digital input, eldbus, etc.
The selected value is the reference for the S-shaped lift ramp.
This setting is taken as the default maintenance speed value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.1.5 11026 Multi speed 3 Hz FLOAT 0.00 -10000 10000 RW FVS
Setting of the multispeed 3 value. Can be selected via digital input, eldbus, etc.
The selected value is the reference for the S-shaped lift ramp.
Attention
