50 ADL300 • Functions description and parameters list
5.9 – LIFT ALARMS
The MdPlc application for ADL300 manages and generates the following alarms:
Alarm Alarm type Description
Plc1 fault Cont feedback Contactor feedback signal error
Plc2 fault Brake feedback Brake feedback signal error
Plc3 fault Door feedback Door feedback signal error
Plc4 fault Brake Failure The Threshold A3 (PAR 11270) threshold has been overcome.
Plc5 fault Not used
Plc6 fault Speed limited Warning of speed limit to guarantee stop
Plc7 fault Up/low limit Speed limit exceeded in power factor regulation zone
Plc8 fault Lift EF alarm sel Associated to Lift EF alarm sel (PAR 11258) input
All alarms are associated with a parameter to congure the action taken when the alarm is activated.
Activity: used to set the action to be performed after activation of the alarm, as follows.
Action
Ignore The alarm is not included in the alarm list, it is not included in the alarm log, it is not signalled on the
digital outputs, commands to the drive are not modied.
Warning The alarm is included in the alarm list, it is included in the alarm log, it is signalled on the digital
outputs, First alarm information is updated, Enabled alarms information is updated, commands to the
drive are not modied.
Disable The alarm is included in the alarm list, it is included in the alarm log, it is signalled on the digital out-
puts, First alarm information is updated, Enabled alarms information is updated, a stop command is
sent, the motor is disabled and stops due to inertia.
Fast Stop The alarm is included in the alarm list, it is included in the alarm log, it is signalled on the digital
outputs, First alarm information is updated, Enabled alarms information is updated, a Stop command
is sent. The drive is set to zero speed with the maximum available current; when the Speed 0 delay
signal is activated the drive is disabled.
Lift Fast stop When there is an alarm occurrence, lift will be stopped (ramp reference is set to zero) immediately
with fast ramp, after that it will remain in alarm state. Attention: this will cause the cabin to stop out of
oor !
Lift stop When there is an alarm occurrence, lift will continue to run until next stop condition, after that it will
remain in alarm state.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.9.1 11058 Lift fast stop fact FLOAT 10.00 1.00 50.00 RW FVS
This parameter is applied to all ramps when a “Quick stop” alarm occurs.
The default setting is 10 = 1000% (standard ramps multiplied by 10).
To use standard ramps with no multiplication, set 1 = 100%.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.9.2 11200 Contactor activity INT16 1 0 5 RW FVS
Setting of drive behaviour in case of a Cont fbk fail alarm. This alarm indicates that the feedback conrming closing of the
contactor has not been received.
0 Ignore
1 Warning
2 Disable
3 Fast Stop
4 Lift Fast stop
5 Lift stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.9.3 11202 Cont hold off ms INT32 3000 RW FVS
Setting of the delay time between activation of the Cont fbk fail alarm condition signal and the actual alarm. In case of an
alarm condition, the drive waits for the set time to elapse before activating the alarm. If the alarm is removed within the set
time, the drive will not activate the alarm.
