ADL300 • Functions description and parameters list 65
15 - ENCODER CONFIG
The closed-loop control mode requires a speed reading by a digital encoder on the motor shaft. The optional card is necessary
in order to acquire the encoder signals. The natural variation in speed generated by machine load induction, known as slippage,
can be compensated by the speed feedback supplied by the encoder in SSC mode. In the eld oriented vector mode, closed-loop
encoder feedback is essential for correct drive operation.
Note ! This menu is only displayed if a feedback card is installed
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.1 2100 Encoder pulses ppr UINT16 1024 128 16384 RWZ FVS
Setting of the number of feedback encoder impulses. During setup, for incremental sinusoidal encoders + absolute EnDat,
encoder absolute EnDat Full digital and Hiperface encoders this value is set automatically by reading the number of incre-
mental encoder impulses.
With the EnDat Full digital Encoder, the value set automatically may be below the minimum.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.2 2102 Encoder supply V FLOAT 5.2 5.2 CALCF ERWZ FVS
Setting of the encoder supply voltage supplied by the relative optional card. Min and max values are modied according to
the type of encoder card applied.
Type of encoder option Def Min Max
Enc 1 EXP-DE-I1R1F2-ADL 5.2 V 5.2 V 22.0 V
Enc 2 EXP-SE-I1R1F2-ADL 5.2 V 5.2 V 6.0 V
Enc 3 EXP-SESC-I1R1F2-ADL 5.2 V 5.2 V 6.0 V
Enc 4 EXP-EN/SSI-I1R1F2-ADL 5.2 V 5.2 V 10.0 V
Enc 5 EXP-HIP-I1R1F2-ADL 8.0 V 7.0 V 12.0 V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.3 2104 Encoder input config ENUM TTL 0 1 ERWZ FVS
Setting of the input conguration of the incremental digital encoder, TTL or HTL.
0 HTL
1 TTL
This parameter is automatically set to HTL when the value set in the Encoder supply parameter is more than 6.0V.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.4 2106 Encoder repetition ENUM No division 0 7 ERWZ FVS
Setting of the divider to apply to the encoder repeat output frequency.
0 No division
1 Divide 2
2 Divide 4
3 Divide 8
4 Divide 16
5 Divide 32
6 Divide 64
7 Divide 128
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.5 2108 Encoder signal Vpp V FLOAT 1 0.8 1.2 ERWZ FVS
Setting of the peak-to-peak voltage value of the encoder signal. Incremental sinusoidal encoders and absolute SinCos
encoders normally produce signals with a peak-to-peak voltage of 1 Vpp. Due to loss of voltage along the cable, the value
of the peak-to-peak voltage signal received by the feedback card could be lower, generating a Speed fbk loss alarm.
This parameter can be used to set the peak-to-peak voltage value of the incremental sinusoidal encoders and absolute
SinCos encoders on the input terminals of the feedback card.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.6 2110 Encoder signal check ENUM Check A-B 0 3 ERWZ FVS
Conguration of which incremental digital encoder channels are to be controlled in order to process the Speed fbk loss
