ADL300 • Functions description and parameters list 97
21.3.35 4104 Fieldbus M->S9 mon INT32 32BIT 0 0 0 ER FVS
21.3.39 4114 Fieldbus M->S10 mon INT32 32BIT 0 0 0 ER FVS
21.3.43 4124 Fieldbus M->S11mon INT32 32BIT 0 0 0 ER FVS
21.3.47 4134 Fieldbus M->S12 mon INT32 32BIT 0 0 0 ER FVS
21.3.51 4144 Fieldbus M->S13 mon INT32 32BIT 0 0 0 ER FVS
21.3.55 4154 Fieldbus M->S14 mon INT32 32BIT 0 0 0 ER FVS
21.3.59 4164 Fieldbus M->S15 mon INT32 32BIT 0 0 0 ER FVS
21.3.63 4174 Fieldbus M->S16 mon INT32 32BIT 0 0 0 ER FVS
The value received from the bus is displayed. This parameter must be associated with the src parameter to enable the
M->S channel.
The user may modify the M->S and by S->M sys parameters. The consistency of the sys with the parameter assigned to
the channel is checked.
A Fieldbus M->S X Mon parameter can only be assigned to a single “src”. If assigned to more than one src, an er-
ror signal is generated during eldbus initialization.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.3.4 4026 Fieldbus M->S1 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.8 4036 Fieldbus M->S2 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.12 4046 Fieldbus M->S3 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.16 4056 Fieldbus M->S4 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.20 4066 Fieldbus M->S5 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.24 4076 Fieldbus M->S6 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.28 4086 Fieldbus M->S7 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.32 4096 Fieldbus M->S8 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.36 4106 Fieldbus M->S9 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.40 4116 Fieldbus M->S10 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.44 4126 Fieldbus M->S11 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.48 4136 Fieldbus M->S12 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.52 4146 Fieldbus M->S13 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.56 4156 Fieldbus M->S14 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.60 4166 Fieldbus M->S15 div FLOAT 1.0 1.0 1000.0 ERW FVS
21.3.64 4176 Fieldbus M->S16 div FLOAT 1.0 1.0 1000.0 ERW FVS
The Div M->Sx eldbus parameters can be used to increase the resolution of the datum sent on the bus to the drive in the
corresponding channel in EU and EU_oat exchange mode. The parameter value is used by the drive as the divider of the
incoming datum, so that a number with decimal digits can be transferred.
Nota! You must check the size in bits of the datum that is sent to make sure that the maximum value in bits fits in a 16-bit integer. For exam-
ple, if specifying the divider as “Fieldbus M->Sn div” = 1000, the maximum value that can be used for the exchanged datum is 32.768
(32768/1000).
Example : Div M->Sx eldbus = 10, M->S1 eldbus par = Ramp ref src 1, Sys M->S1 eldbus = EU. If the PLC sends
the decimal value 1000 on the rst word the value of ramp ref 1 on the drive is 1000/10 = 100.
21.4 - COMMUNICATION/FIELDBUS S2M
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.4.1 4180 Fieldbus S->M1 ipa FBS2MIPA
0 0 20000 ERW FVS
21.4.5 4190 Fieldbus S->M2 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.9 4200 Fieldbus S->M3 ipa
FBS2MIPA 0 0 20000 ERW FVS
21.4.13 4210 Fieldbus S->M4 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.17 4220 Fieldbus S->M5 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.21 4230 Fieldbus S->M6 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.25 4240 Fieldbus S->M7 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.29 4250 Fieldbus S->M8 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.33 4260 Fieldbus S->M9 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.37 4270 Fieldbus S->M10 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.41 4280 Fieldbus S->M11 ipa FBS2MIPA 0 0 20000 ERW FVS
