54 ADL300 • Functions description and parameters list
10 - DIGITAL INPUTS
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
10.01 1240 Dig inp 1X inversion BIT 0 0 1 ERW FVS
10.02 1242 Dig inp 2X inversion BIT 0 0 1 ERW FVS
10.03 1244 Dig inp 3X inversion BIT 0 0 1 ERW FVS
10.04 1246 Dig inp 4X inversion BIT 0 0 1 ERW FVS
10.05 1248 Dig inp 5X inversion BIT 0 0 1 ERW FVS
10.06 1250 Dig inp 6X inversion BIT 0 0 1 ERW FVS
10.07 1252 Dig inp 7X inversion BIT 0 0 1 ERW FVS
10.08 1254 Dig inp 8X inversion BIT 0 0 1 ERW FVS
10.09 1256 Dig inp 9X inversion BIT 0 0 1 ERW FVS
10.10 1258 Dig inp 10X inversion BIT 0 0 1 ERW FVS
10.11 1260 Dig inp 11X inversion BIT 0 0 1 ERW FVS
10.12 1262 Dig inp 12X inversion BIT 0 0 1 ERW FVS
Inversion of the logic status of the function associated with the digital input of the expansion card.
0 O
1 On
Note ! The parameters Dig inp 9X inversion ... Dig inp 12X inversion are available only in the ADL300A version with a specific expansion card. See
the ADL300 QS manual.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
10.13 1268 Dig input E dest ILINK 0 0 0 ER FVS
10.14 1270 Dig input 1X dest ILINK 0 0 0 ER FVS
10.15 1272 Dig input 2X dest ILINK 0 0 0 ER FVS
10.16 1274 Dig input 3X dest ILINK 0 0 0 ER FVS
10.17 1276 Dig input 4X dest ILINK 0 0 0 ER FVS
10.18 1278 Dig input 5X dest ILINK 0 0 0 ER FVS
10.19 1280 Dig input 6X dest ILINK 0 0 0 ER FVS
10.20 1282 Dig input 7X dest ILINK 0 0 0 ER FVS
10.21 1284 Dig input 8X dest ILINK 0 0 0 ER FVS
10.22 1286 Dig input 9X dest ILINK 0 0 0 ER FVS
10.23 1288 Dig input 10X dest ILINK 0 0 0 ER FVS
10.24 1290 Dig input 11X dest ILINK 0 0 0 ER FVS
10.25 1292 Dig input 12X dest ILINK 0 0 0 ER FVS
Selection of the destination of the digital input of the associated expansion card.
Note ! The parameters Dig input 9X dest ... Dig input 12X dest are available only in the ADL300A version with a specific expansion card. See the
ADL300 QS manual.
