10 ADL300 • Functions description and parameters list
2 - DRIVE INFO
This menu displays the information for identifying and conguring the drive.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.1 476 Drive type ENUM Basic-Sin 1 0 R FVS
The drive series identication code is displayed.
The drives reporting 24V in the description can be feeded by an external 24Vdc power supply. For schematics and connec-
tion diagrams please refer to Quick Start manual.
0 Basic-Sin
1 Advanced
2 Basic-VGA
3 Basic-End
128 Basic-Sin 24V
129 Advanced 24V
130 Basic-VGA 24V
131 Basic-End 24V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.2 480 Control type ENUM Asynchronous 0 0 R FVS
The control mode is displayed.
11 Asynchronous
12 Synchronous
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.3 482 Drive size UINT16 0 0 0 RS FVS
The drive size identication code is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.4 484 Drive family ENUM No Power 0 0 RS FVS
The available mains voltage is displayed (e.g. 400V). The undervoltage alarm refers to this voltage value.
The condition No power occurs when the regulation board has just left from production and has never been congured for
any power. The conguration adjustment for a given power is achieved by linking it to a power board and running a Save
parameters.
0 No Power
1 230V..480V
2 500V..575V
3 690V
4 230V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.5 486 Drive region ENUM EU 0 1 R FVS
Setting of the geographical area in which the drive is to be used (Europe or USA). This setting determines the factory volt-
age and power supply frequency values.
0 EU (400V / 50Hz)
1 USA (460 / 60 Hz)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.6 488 Drive cont current A FLOAT CALCF 0.0 0.0 RZS FVS
The current that the drive can deliver continuously according to size, supply voltage and programmed switching frequency
is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.7 490 Firmware ver.rel UINT16 0 0 0 R FVS
The version number and release number of the drive rmware are displayed. On the keypad these are displayed in the ver-
sion.release format. The parameter reading from the serial communication device or eldbus returns the version in the high
byte and the release in the low byte.
