ADL300 • Functions description and parameters list 37
5.7 – INPUT/OUTPUT
Inputs
The lift application input commands can be connected to a signal via a selector in order to choose from a series of possibilities
available in the input list.
Generally speaking a signal can be connected to a digital input, to certain internal signals and to a bit of the Decomp word bit. This
word is connected to a eldbus processing channel (PDC FieldBus M->S1).
The set of digital inputs in a word is displayed in the Lift control word.
The commands used in the lift application are listed below
Command Description Default Source
EnableCmd Enable command Dig input enable
StartFwdCmd Start forward command Dig input 1x
StartRevCmd Start reverse command Dig input 2x
MltSpd S0 Multispeed 0 sel Dig input 4x
MltSpd S1 Multispeed 1 sel Dig input 5x
MltSpd S2 Multispeed 2 sel Dig input 6x
ContFbk Contactor close contact Run cont mon
BrakeFbk Brake close contact Brake cont mon
DoorOpenEna Source for enabling the door open function Null
DoorFbk Door close contact Null
Emergency mode Emergency operation command Dig input 3x
InvRampSrc Command to invert the speed direction Null
UpperLimit Travel upper limit signal Null
LowerLimit Travel lower limit signal Null
Outputs
The output signals of the lift control are connected directly to the PAD parameters as shown in the table below:
PAR Signal Description
3700 Lift enable LiftEnable Enable lift command
3702 Run cont mon RunCont Close contactor command
3704 Up cont mon UpCont Up contactor command
3706 Down cont mon DownCont Down contactor command
3708 Brake cont mon BrakeCont Brake command
3710 Lift dc brake LiftDcBrake DC brake function command
3712 Brake 2 mon Brake2 Brake control signal
3714 Door open mon DoorOpen Open door command
3716 Lift start LiftStart Start lift command
3718 PAD10 -----
3720 Lift status word Lift status word Contains pairs of the StatusWord (selectable from SelLiftStatWord)
3722 PAD12 -----
3724 PAD13 -----
3726 Ramp down limit ----- Ramp down current limit
3728
PAD15 -----
3730 Lift wdec input LiftWdecInp Connected to the selector for LifWDecomp
These can be accessed from the selection lists and can thus easily be used to congure the relay and digital outputs of the drive.
(refer to the PADS menu for conguration).
The set of lift output signals is contained in the LiftStatusWord, connected to PAR 3720 Lift status word and eldbus Tx DW1:
Bit Description Notes
0 LiftEnable Enable lift command.
1 RunCont Run command contactor
2 UpCont Up command contactor
3 DownCont Down command contactor
4 BrakeCont Brake command contactor
5 LiftDcBrake DC brake function command (firmware)
6 Brake2 Brake control signal (see sequences)
7 DoorOpen Open door command
8 Drive Ok Drive not in alarm condition signal
9 SpeedIsZero Speed less than 0 limit signal
10 SpeedRefIsZero Speed reference less than 0 limit signal
11 ... 12
