ADL300 • Functions description and parameters list 91
20.8.16 3730 Lift wdec input INT32 32BIT 0 0 0 ERW FVS
Setting of general, 32 Bit variables. PAD parameters can be used as supporting parameters to send values written by the
eldbus, serial line, etc. to analog or digital outputs.
20.9 - FUNCTIONS/DIRECTION COUNT
The “Change ride direction count” function monitors usage of the ropes or belts, signals when maintenance/replacement is needed,
and locks the lift if limits of usage are reached. This function is reserved to lift maintenance personnel and is protected by a specic
password.
Rope usage is typically measured in “changes of direction”: the maximum number is specied on a certicate supplied by the rope
manufacturer.
A specic counter keeps count of direction changes and can be reset when the ropes are replaced.
The following signals, inserted in the L_DIGSEL1 selection list, can be brought to a digital output: PAR 3420 Ropes change req
mon, PAR 3422 Direction change mon and PAR 3424 Dir change cnt zero.
IN parameters
PAR 3400 Direction cnt enable
>
ADL300
PAR 3414 Direction counter
>
OUT parameters
Enable direction change function Direction change counter
PAR 3412 Ropes usage
>
PAR 3408 Dir cnt password
>
Ropes usage percentage
Counter reset password
PAR 3416 Prev direct counter
>
Residual previous set of ropes
PAR 3402 Max direction cnt
>
Max. no. direction changes PAR 3418 No of cnt reset
>
No. ropes replacement
Digital outputs
[31] Rope change
>
PAR 3404 Ropes change thr
>
Ropes usage alarm
Preventive usage threshold
PAR 3424 Dir change cnt zero
>
Lift lock
PAR 3406 Direction cnt reset
>
PAR 3422 Direction change mon
>
Reset direction change counter Direction change counter
.
Firmware update
To keep them from being overwritten when using Gefran eXpress, these parameters are not updated with the Write all
target parameters operation.
Replacing the drive
If the drive is replaced, you can save the conguration of the “Direction change count” function on the keypad (PAR 3434
Save to keypad) and load it on the new drive (PAR 3436 Load from keypad).
Password
All of the parameters of this function, reserved to lift maintenance personnel, are protected by a specic password.
The password is managed via parameters PAR 3408 Dir cnt password and PAR 3410 Dir cnt new password.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.1 3400 Direction cnt enable ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
Enables the “Direction change count” function.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.2 3402 Max direction cnt UINT32 0 0 2147483647 ERW FVS
Sets the maximum allowed number of direction changes.
Importante!
