92 ADL300 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.3 3404 Ropes change thr perc UINT16 0 0 100 ERW FVS
Sets a usage threshold beyond which the “Rope change” alarm is signalled to indicate that the ropes have to be replaced.
When parameter 3412 Ropes usage exceeds this threshold, the drive keeps running but the alarm stays on to remind the
operator to replace the ropes.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.4 3406 Direction cnt reset ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
Let you run a reset to return the direction change counter to the initial value of parameter 3402 Max direction cnt (value
set by rope manufacturer).
This operation is password-protected and must be run when the ropes are changed.
Executing this command causes the following:
1. the value of counter 3414 Direction counter is copied to parameter 3416 Prev direct counter,
2. the value of parameter 3414 No of cnt reset is incremented,
3. counter 3414 Direction counter is reset to value 3402 Max direction cnt and consequently parameter 3412 Ropes
usage is reset to 0.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.5 3408 Dir cnt password UINT16 0 0 9999 ERW FVS
This parameter is used to enter the password (max 4 numbers) to protect the “Direction change count” menu. The pass-
word is displayed only when it is entered; when not in this mode the display shows 0.
When the password has been entered, you can change it by entering a new one in PAR 3410 Dir cnt new password..
The password is not reset when reloading default parameters and is also maintained when updating rmware.
Attention: if you forget the password you have to contact Gefran Technical Service.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.6 3410 Dir cnt new password UINT16 0 0 9999 ERW FVS
This parameter lets you change the password to replace the one entered in par 3408 Dir cnt password.
A combination of a maximum of 4 numbers is allowed. To access this parameter, you have to enable the menu by entering
the old password in PAR 3408.
The password must be entered twice to be enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.7 3412 Ropes usage perc UINT16 16BIT 0 0 0 ER FVS
Displays the ropes usage counter (as percentage) of parameter 3402 Max direction cnt.
When PAR 3412 = 100% (corresponds to PAR 3414 = 0), the ropes have reached their useful life and must be replaced:
the drive nishes the current travel and then locks.
By switching the drive o󰀨 and back on you can run a single travel to bring the car to a better position for the procedure.
To eliminate the lock condition, reset the direction change counter.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.8 3414 Direction counter UINT32 32BIT 0 0 0 ER FVS
Displays the countdown of direction changes remaining until useful life of the ropes is reached.
When PAR 3414 = “0” the ropes must be replaced (corresponds to PAR 3412 = 100%): the drive nishes the current travel
and then locks.
By switching the drive o󰀨 and back on you can run a single travel to bring the car to a better position for the procedure.
To eliminate the lock condition, reset the direction change counter (see PAR 3406 Direction cnt reset).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9.9 3416 Prev direct counter UINT32 32BIT 0 0 0 ER FVS
Importante!
