90 ADL300 • Functions description and parameters list
4 Inp1>Inp2
5 |Inp1|=|Inp2|
6 |Inp1|!=|Inp2|
7 |Inp1|<|Inp2|
8 |Inp1|>|Inp2|
If set to 0 the comparator is not enabled
If set to 1 the comparator output is enabled when the value of Dig compare input 1 is inside the window resulting from the
value of Dig compare input 2 ± the tolerance set via the Comparator Window.
If set to 2 the comparator output is enabled when the value of Dig compare input 1 is not inside the window resulting from
the value of Dig compare input 2 ± the tolerance set via the Comparator Window.
If set to 3 the comparator output is enabled when Compare input 1 is less than Compare input 2.
If set to 4 the comparator output is enabled when Compare input 1 is greater than Compare input 2.
If set to 5 the comparator output is enabled when the value of Dig compare input 1 is inside the window resulting from the
absolute value of Dig compare input 2 ± the tolerance set via the Comparator Window.
If set to 6 the comparator output is enabled when the absolute value of Dig compare input 1 is not inside the window
resulting from the absolute value of Dig compare input 2 ± the tolerance set via the Comparator Window.
If set to 7 the comparator output is enabled when the absolute value of Dig compare input 1 is less than the absolute
value of Dig compare input 2.
If set to 8 the comparator output is enabled when the absolute value of Digital compar inp1 is more than the absolute
value of Digital compar in2.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.7.6 3672 Compare window perc FLOAT 0.0 0.0 100.0 ERW FVS
Setting of the tolerance window for comparing the Compare input 1 and Compare input 2 signals.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.7.7 3674 Compare delay s FLOAT 0.0 0.0 30.0 ERW FVS
Setting of the delay for signalling the result of the comparison.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.7.8 3676 Compare output BIT 16BIT 0 0 1 ER FVS
The status of the comparator output is displayed:
0 The result of the set comparison is negative
1 The result of the set comparison is positive
20.8 - FUNCTIONS/PADS
The general variables are used to exchange data between the various components of a Bus system. They are similar to the vari-
ables of a PLC. Pads can be used, for example, to send information from a eldbus to an optional card. All Pads can be read and
written.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.8.1 3700 Lift enable INT32 32BIT 0 0 0 ERW FVS
20.8.2 3702 Run cont mon INT32 32BIT 0 0 0 ERW FVS
20.8.3 3704 Up cont mon INT32 32BIT 0 0 0 ERW FVS
20.8.4 3706 Down cont mon INT32 32BIT 0 0 0 ERW FVS
20.8.5 3708 Brake cont mon INT32 32BIT 0 0 0 ERW FVS
20.8.6 3710 Lift dc brake INT32 32BIT 0 0 0 ERW FVS
20.8.7 3712 Brake 2 mon INT32 32BIT 0 0 0 ERW FVS
20.8.8 3714 Door open mon INT32 32BIT 0 0 0 ERW FVS
20.8.9 3716 Lift start INT32 32BIT 0 0 0 ERW FVS
20.8.10 3718 Pad 10 INT32 32BIT 0 0 0 ERW FVS
20.8.11 3720 Lift status word INT32 32BIT 0 0 0 ERW FVS
20.8.12 3722 Pad 12 INT32 32BIT 0 0 0 ERW FVS
20.8.13 3724 Pad 13 INT32 32BIT 0 0 0 ERW FVS
20.8.14 3726 Ramp down limit INT32 32BIT 0 0 0 ERW FVS
20.8.15 3728 PAD 15 INT32 32BIT 0 0 0 ERW FVS
