116 ADL300 • Selection lists
PAR Description Menu
PAR Description Menu PAR Description Menu
C - SELECTION LISTS
L_ANOUT
6000 Null (*)
626 Ramp ref out mon (*)
760 Ramp out mon (*)
664 Speed setpoint 1.5
260 Motor speed 1.6
262 Motor speed nolter (*)
2150 Encoder speed 15.21
250 Output current 1.1
252 Output voltage 1.2
254 Output frequency 1.3
280 Torque current ref 1.9
282 Magnet current ref 1.10
284 Torque current 1.11
286 Magnet current 1.12
2360 Torque climPos Inuse 18.5
2362 Torque climNeg Inuse 18.6
2386 Torque ref 18.10
2388 Torque ref nolter (*)
270 DC link voltage 1.7
3104 Inertia comp mon 20.1.3
1600 Analog input 1X mon 12.1
1650 Analog input 2X mon 12.12
368 Drive overload accum 1.14
3212 Motor overload accum 1.13
3260 Bres overload accum 1.15
2232 Spd reg P gain Inuse 16.16
2234 Spd reg I gain Inuse 16.17
4024 Fieldbus M->S1 mon 21.3.3
4034 Fieldbus M->S2 mon 21.3.7
4044 Fieldbus M->S3 mon 21.3.11
4054 Fieldbus M->S4 mon 21.3.15
4064 Fieldbus M->S5 mon 21.3.19
4074 Fieldbus M->S6 mon 21.3.23
4084 Fieldbus M->S7 mon 21.3.27
4094 Fieldbus M->S8 mon 21.3.31
4104 Fieldbus M->S9 mon 21.3.35
4114 Fieldbus M->S10 mon 21.3.39
4124 Fieldbus M->S11 mon 21.3.43
4134 Fieldbus M->S12 mon 21.3.47
4144 Fieldbus M->S13 mon 21.3.51
4154 Fieldbus M->S14 mon 21.3.55
4164 Fieldbus M->S15 mon 21.3.59
4174 Fieldbus M->S16 mon 21.3.63
3700 Lift enable 20.8.1
3702 Run cont mon 20.8.2
3704 Up cont mon 20.8.3
3706 Down cont mon 20.8.4
3708 Brake cont mon 20.8.5
3710 Lift dc brake 20.8.6
3712 Brake 2 mon 20.8.7
3714 Door open mon 20.8.8
3716 Lift start 20.8.9
3718 Pad 10 20.8.10
3720 Lift status word 20.8.11
3722 Pad 12 20.8.12
3724 Pad 13 20.8.13
3726 Ramp down limit 20.8.14
3728 PAD 15 20.8.15
3730 Lift wdec input 20.8.16
5008 Test gen out 24.1.5
L_CMP
XXXX
(1)
626 Ramp ref out mon (*)
760 Ramp out mon (*)
664 Speed setpoint 1.5
260 Motor speed 1.6
262 Motor speed nolter (*)
2150 Encoder speed 15.21
250 Output current 1.1
252 Output voltage 1.2
254 Output frequency 1.3
280 Torque current ref 1.9
282 Magnet current ref 1.10
284 Torque current 1.11
286 Magnet current 1.12
2386 Torque ref 18.10
2388 Torque ref nolter (*)
270 DC link voltage 1.7
1600 Analog input 1X mon 12.1
1650 Analog input 2X mon 12.12
368 Drive overload accum 1.14
3212 Motor overload accum 1.13
3260 Bres overload accum 1.15
4024 Fieldbus M->S1 mon 21.3.3
4034 Fieldbus M->S2 mon 21.3.7
4044 Fieldbus M->S3 mon 21.3.11
4054 Fieldbus M->S4 mon 21.3.15
4064 Fieldbus M->S5 mon 21.3.19
4074 Fieldbus M->S6 mon 21.3.23
4084 Fieldbus M->S7 mon 21.3.27
4094 Fieldbus M->S8 mon 21.3.31
4104 Fieldbus M->S9 mon 21.3.35
4114 Fieldbus M->S10 mon 21.3.39
4124 Fieldbus M->S11 mon 21.3.43
4134 Fieldbus M->S12 mon 21.3.47
4144 Fieldbus M->S13 mon 21.3.51
4154 Fieldbus M->S14 mon 21.3.55
4164 Fieldbus M->S15 mon 21.3.59
4174 Fieldbus M->S16 mon 21.3.63
3700 Lift enable 20.8.1
3702 Run cont mon 20.8.2
3704 Up cont mon 20.8.3
3706 Down cont mon 20.8.4
3708 Brake cont mon 20.8.5
3710 Lift dc brake 20.8.6
3712 Brake 2 mon 20.8.7
3714 Door open mon 20.8.8
3716 Lift start 20.8.9
3718 Pad 10 20.8.10
3720 Lift status word 20.8.11
3722 Pad 12 20.8.12
3724 Pad 13 20.8.13
3726 Ramp down limit 20.8.14
3728 PAD 15 20.8.15
3730 Lift wdec input 20.8.16
(1)
the XXXX parameter changes according
to the src parameter used:
3660 Compare input 1 src
(1)
= 3650 Dig compare input 1 20.7.1
3662 Compare input 2 src
(1)
= 3652 Dig compare input 2 20.7.2
L_DIGSEL1
6000 Null (*)
6002 One (*)
1110 Digital input E mon (*)
1210 Digital input 1X mon (*)
1212 Digital input 2X mon (*)
1214 Digital input 3X mon (*)
1216 Digital input 4X mon (*)
1218 Digital input 5X mon (*)
1220 Digital input 6X mon (*)
1222 Digital input 7X mon (*)
1224 Digital input 8X mon (*)
1226 Digital input 9X mon (*)
1228 Digital input10X mon (*)
1230 Digital input11X mon (*)
1232 Digital input12X mon (*)
1062 Drive OK (*)
1064 Drive ready (*)
934 Ref is 0 (*)
936 Ref is 0 delay (*)
944 Speed is 0 (*)
946 Speed is 0 delay (*)
1066 Enable state mon 1.16
1068 Start state mon 1.17
1070 FastStop state mon 1.18
1024 Enable cmd mon 9.12
1026 Start cmd mon 9.13
1028 FastStop cmd mon 9.14
4708 Alm dig out mon 1 (*)
4710 Alm dig out mon 2 (*)
4712 Alm dig out mon 3 (*)
4714 Alm dig out mon 4 (*)
362 Drive overload trip (*)
3214 Motor overload trip (*)
3262 Bres overload trip (*)
366 Drive overload 80% (*)
4454 Bit0 decomp mon 21.6.3
4456 Bit1 decomp mon 21.6.4
4458 Bit2 decomp mon 21.6.5
4460 Bit3 decomp mon 21.6.6
4462 Bit4 decomp mon 21.6.7
4464 Bit5 decomp mon 21.6.8
4466 Bit6 decomp mon 21.6.9
4468 Bit7 decomp mon 21.6.10
4470 Bit8 decomp mon 21.6.11
4472 Bit9 decomp mon 21.6.12
4474 Bit10 decomp mon 21.6.13
4476 Bit11 decomp mon 21.6.14
4478 Bit12 decomp mon 21.6.15
4480 Bit13 decomp mon 21.6.16
4482 Bit14 decomp mon 21.6.17
4484 Bit15 decomp mon 21.6.18
3700 Lift enable 20.8.1
3702 Run cont mon 20.8.2
3704 Up cont mon 20.8.3
3706 Down cont mon 20.8.4
3708 Brake cont mon 20.8.5
3710 Lift dc brake 20.8.6
3712 Brake 2 mon 20.8.7
3714 Door open mon 20.8.8
3716 Lift start 20.8.9
3718 Pad 10 20.8.10
3720 Lift status word 20.8.11
3722 Pad 12 20.8.12
3724 Pad 13 20.8.13
3726 Ramp down limit 20.8.14
3728 PAD 15 20.8.15
3730 Lift wdec input 20.8.16
6006 Current limit state (*)
764 Ramp acc state (*)
766 Ramp dec state (*)
4780 Alarm PLC (*)
3676 Compare output 20.7.8
3420 Ropes change req mon 20.9.11
