ADL300 • Functions description and parameters list 99
21.4.15 4214 Dig Fieldbus S->M4 INT32 32BIT 0 0 0 ERW FVS
21.4.19 4224 Dig Fieldbus S->M5 INT32 32BIT 0 0 0 ERW FVS
21.4.23 4234 Dig Fieldbus S->M6 INT32 32BIT 0 0 0 ERW FVS
21.4.27 4244 Dig Fieldbus S->M7 INT32 32BIT 0 0 0 ERW FVS
21.4.31 4254 Dig Fieldbus S->M8 INT32 32BIT 0 0 0 ERW FVS
21.4.35 4264 Dig Fieldbus S->M9 INT32 32BIT 0 0 0 ERW FVS
21.4.39 4274 Dig Fieldbus S->M10 INT32 32BIT 0 0 0 ERW FVS
21.4.43 4284 Dig Fieldbus S->M11 INT32 32BIT 0 0 0 ERW FVS
21.4.47 4294 Dig Fieldbus S->M12 INT32 32BIT 0 0 0 ERW FVS
21.4.51 4304 Dig Fieldbus S->M13 INT32 32BIT 0 0 0 ERW FVS
21.4.55 4314 Dig Fieldbus S->M14 INT32 32BIT 0 0 0 ERW FVS
21.4.59 4324 Dig Fieldbus S->M15 INT32 32BIT 0 0 0 ERW FVS
21.4.63 4334 Dig Fieldbus S->M16 INT32 32BIT 0 0 0 ERW FVS
If associated with the relative src, the value of this parameter is sent to the bus.
The user may modify the M->S and by S->M sys parameters. The consistency of the sys with the parameter assigned to
the channel is checked.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.4.4 4186 Fieldbus S->M1 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.8 4196 Fieldbus S->M2 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.12 4206 Fieldbus S->M3 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.16 4216 Fieldbus S->M4 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.20 4226 Fieldbus S->M5 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.24 4236 Fieldbus S->M6 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.28 4246 Fieldbus S->M7 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.32 4256 Fieldbus S->M8 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.36 4266 Fieldbus S->M9 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.40 4276 Fieldbus S->M10 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.44 4286 Fieldbus S->M11 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.48 4296 Fieldbus S->M12 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.52 4306 Fieldbus S->M13 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.56 4316 Fieldbus S->M14 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.60 4326 Fieldbus S->M15 mul FLOAT 1.0 1.0 1000.0 ERW FVS
21.4.64 4336 Fieldbus S->M16 mul FLOAT 1.0 1.0 1000.0 ERW FVS
The “Fieldbus S->Mx mul” parameters are multipliers that the drive applies to the datum before sending it to the bus. It is
therefore possible to increase the resolution of some values read in EU and EU_oat mode, also using decimal digits.
Note! The drive does not check that the multiplied parameter expressed in bits fits in a 16-bit integer. You must make sure that the multiplier is com-
patible with the maximum value of the exchanged parameter and that it does not exceed the maximum size of 32768.
Example: Fieldbus S->Mx mul = 10, S->M1 eldbus par = Motor speed, Sys S->M1 eldbus = EU.
If the motor is running at 100 rpm, the PLC reads the value 100 * 10 = 1000 on the rst word that is exchanged.
21.5 - COMMUNICATION/WORD COMP
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.5.1 4400 Word bit0 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.2 4402 Word bit1 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.3 4404 Word bit2 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.4 4406 Word bit3 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.5 4408 Word bit4 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.6 4410 Word bit5 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.7 4412 Word bit6 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.8 4414 Word bit7 src LINK 16BIT 6000 0 16384 ERW FVS
21.5.9 4416 Word bit8 src LINK 16BIT 6000 0 16384 ERW FVS
