gefran SIEIDrive ADL300 Functions Description And Parameters List

98 ADL300 • Functions description and parameters list
21.4.45 4290 Fieldbus S->M12 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.49 4300 Fieldbus S->M13 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.53 4310 Fieldbus S->M14 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.57 4320 Fieldbus S->M15 ipa FBS2MIPA 0 0 20000 ERW FVS
21.4.61 4330 Fieldbus S->M16 ipa FBS2MIPA 0 0 20000 ERW FVS
Setting of the parameter to associate with the bus channel. The default setting is 0, which means channel not active.
When setting a parameter, the format is also automatically set in the sys parameter
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.4.2 4182 Fieldbus S->M1 sys ENUM Not assigned 0 10 ERW FVS
21.4.6 4192 Fieldbus S->M2 sys ENUM Not assigned 0 10 ERW FVS
21.4.10 4202 Fieldbus S->M3 sys ENUM Not assigned 0 10 ERW FVS
21.4.14 4212 Fieldbus S->M4 sys ENUM Not assigned 0 10 ERW FVS
21.4.18 4222 Fieldbus S->M5 sys ENUM Not assigned 0 10 ERW FVS
21.4.22 4232 Fieldbus S->M6 sys ENUM Not assigned 0 10 ERW FVS
21.4.26 4242 Fieldbus S->M7 sys ENUM Not assigned 0 10 ERW FVS
21.4.30 4252 Fieldbus S->M8 sys ENUM Not assigned 0 10 ERW FVS
21.4.34 4262 Fieldbus S->M9 sys ENUM Not assigned 0 10 ERW FVS
21.4.38 4272 Fieldbus S->M10 sys ENUM Not assigned 0 10 ERW FVS
21.4.42 4282 Fieldbus S->M11 sys ENUM Not assigned 0 10 ERW FVS
21.4.46 4292 Fieldbus S->M12 sys ENUM Not assigned 0 10 ERW FVS
21.4.50 4302 Fieldbus S->M13 sys ENUM Not assigned 0 10 ERW FVS
21.4.54 4312 Fieldbus S->M14 sys ENUM Not assigned 0 10 ERW FVS
21.4.58 4322 Fieldbus S->M15 sys ENUM Not assigned 0 10 ERW FVS
21.4.62 4332 Fieldbus S->M16 sys ENUM Not assigned 0 10 ERW FVS
Setting of the format of the datum sent to the channel. When the src parameter is programmed, the format is programmed
as EU or MDPLC 16. If the src parameter is reset to null, the datum format does not change. The value of the format can
be selected from the following list:
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
5 Mdplc 16
6 Mdplc 32
7 EU
8 EU oat
9 Par 16
10 Par 32
If set to 0 the channel is not assigned.
If set to 1 the datum is assigned a 16-bit count.
If set to 2 the datum is assigned a 32-bit count.
If set to 3 16 bits on the channel are reserved for the datum, not used.
If set to 4 32 bits on the channel are reserved for the datum, not used.
If set to 5 the datum is assigned a 16-bit count used by MDPLC.
If set to 6 the datum is assigned a 32-bit count used by MDPLC.
If set to 7 the datum is assigned engineering units on a 16-bit integer.
If set to 8 the datum is assigned engineering units on a 32-bit integer.
If set to 9, the datum is assigned a 16-bit integer engineering unit format not in real time (5-10ms)
If set to 10 the datum is assigned a 32-bit integer engineering unit format or oat format if the associated parameter is a
oat-type parameter not in real time (5-10ms)
Note! If the sys parameter is not assigned, none of the subsequent channels are transferred to the fieldbus, even if programmed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
21.4.3 4184 Dig Fieldbus S->M1 INT32 32BIT 0 0 0 ERW FVS
21.4.7 4194 Dig Fieldbus S->M2 INT32 32BIT 0 0 0 ERW FVS
21.4.11 4204 Dig Fieldbus S->M3 INT32 32BIT 0 0 0 ERW FVS
