ADL300 • Functions description and parameters list 9
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.13 3212 Motor overload accum UINT16 16/32BIT 0 0 100 ER FVS
The motor overload level is displayed (100% = alarm threshold).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.14 368 Drive overload accum UINT16 16/32BIT 0 0 100 ER FVS
The drive overload level is displayed. An instantaneous overload of 200% of the drive rated current is allowed for 10s. The
thermal image I²t adjusts the drive output current thresholds. During normal operation, the instantaneous output current
value can reach 200% of the drive rated current. When the overload level par. 368 Drive overload accum reaches 100%,
the output current threshold is reduced to 100% of the rated current, and stays at that value until the I²t integrator cycle is
complete. At this point the instantaneous overload of 200% or 150% (below 3Hz) will be re-activated.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.15 3260 Bres overload accum UINT16 16/32BIT 0 0 100 ER FVS
The braking resistor overload limit is displayed (100% = alarm threshold).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.16 1066 Enable state mon BIT 16BIT 0 0 1 R FVS
The drive Enable command status is displayed. Voltage must be present on terminal 7. The FR Forwardstart command is
needed to start the inverter.
1 Enabled drive enabled
0 Disabled drive disabled
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.17 1068 Start state mon BIT 16BIT 0 0 1 R FVS
The drive Start command status is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.18 1070 FastStop state mon BIT 16BIT 0 0 1 R FVS
The drive FastStop command status is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.19 1200 Digital input X mon UINT16 16BIT 0 0 0 R FVS
The status of the digital inputs of the expansion card is displayed. It can also be read via a serial line or eldbus. The data
are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
1 Input enabled.
0 Input disabled.
Example:
0 0 0 0 0 0 0 0 0 0 1 1
Enable
DI 1
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.20 1400 Digital output X mon UINT16 0 0 0 R FVS
The status of the digital outputs of the expansion card is displayed. It can also be read via a serial line or eldbus. The data
are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
1 Output enabled.
0 Output disabled.
Example:
0 0 0 0 0 0 0 0 0 0 1 1
DO 1
DO 2
