Generac Power Systems CorePower User Manual

PART 5
DISASSEMBLY
Page 84
Section 5.1
Major Disassembly
9. Disconnect the voltage regulator.
Figure 73.
10. Disconnect the ground and neutral connections.
Figure 74.
11. Using an 8mm socket remove the two bolts supporting
the muffler.
Figure 75.
Figure 76.
12. Disconnect the fuel supply hose from the air box
assembly.
Figure 77.

Generac Power Systems CorePower Specifications

General

Brand	Generac Power Systems
Model	CorePower
Category	Portable Generator
Language	English
