enVision Overview 19
Using the enVision with GA
The enVision can be completely controlled from the GA version 6.2 (and
higher) plot program by using controls in the Plotter Settings dialog box.
Use of this dialog box is explained in the GRAPHIX ADVANTAGE Reference
Volume 1 manual. Several comments specific to using the dialog box with the
enVision are explained here.
When an enVision plotter is selected, the color and material (also called the
vinyl family) is displayed.
The GA 6.2 plot program has a rule set
−
as described in the previous
paragraph
−
as part of the program. This rule set is more comprehensive
than the rule set built into the plotter. The Plotter Settings slide bars display
the default settings for the material, and the settings can be changed using
the slide bars.
Note: The plot program in GA version 6.0 and earlier does not contain a
rule set. When using these versions, settings may be adjusted at the
enVision control pad.
When the Use Settings check box is turned on, the rule set for the displayed
material is transmitted to the plotter and overrides any rule set turned on in
the plotter. If the Use Setting check box is turned off, the rule set in the
enVision is used to plot the job.
