Vapodest 50s carousel
3.1. Warranty conditions
Vapodest 50 carousel is designed and fabricated following the high quality guide-
lines of DIN EN ISO 9001.On the basis of the C. Gerhardt conditions of warranty
our products are guaranteed for 1 year as long as the equipment is used according
to the instructions in this manual. Also ll out the "Report for the installation and
initial operation" and send back to C. Gerhardt.
Please note that the following parts are excluded from warranty.
- Digestion tube, Order-no.: 12-0301
- Vitone cone, Order-no.: 12-0351
3.2. Technical data
Nominal voltage: 230 V AC 50 Hz oder 115 V 60 Hz oder
230 V 60 Hz
Nominal wattage: 1830 W
Cooling water consumption: about 3 liters per distillation minute
Cooling water pressure min. 0,5 bar, max. 6 bar
Pump capacity (read chapter 7.9. calibration dosing pumps)
- Diaphragm pump about. 15 ml/s with water
about 10 ml/s with NaOH
- Peristaltic pump about 10 ml/s with water
Storage tanks: 2 x 20 Liter, 2 x 10 Liter, 1 x 5 Liter
Display: LED with illumination
Number of programs: unlimited
Dimensions: 1010 x 670 x 1655 mm (B x T x H)
(1290 mm with board attached on the side)
Weight: 190 kg
Recovery rate: > 99,5 %
Reproducibility: +/- 1 %
Detection limit: 0,1 mg N
Interfaces:
- Vapodest 2 x RS 485 interface: Connection for GerBus®
1 x 5-5-pin connector for level sensor
- ComBox 2 x USB, 1 x RS 485 for GerBus®,
1 x RS 232 connection for balance
Micro dosing pump: Deviation of ow rate < 0,2 %
PC-requirements: IBM compatible PC with Windows XP (recomm.) or Vista
Min. 512 MB RAM - Min. 1 Ghz Prozessor -
Min. 20 GB harddisk - Min. 1 USB port
3 Technical description
