Vapodest 50s carousel
7 System settings
7.10. Service-System functions
The following system functions are only used for service by an authorized cus-
tomer service or the administrator. Usually, no changes of these functions are
necessary.
7.10.1. Calibrate titration dosing pump
From the menu bar select System > Service > Adjustment > Calibrate titration
dosing pump
The delivery volume of the micro dosing pump is set here. The calibration is done
by C.Gerhardt so that a calibration is not necessary.
In the following cases, we recommend a calibration:
- The results are always too high
- The results are always too low
- the volume to the pump has been altered
You can check the pump capacity with the help of the rinsing program as described
in chapter "7.7. Rinse micro dosing pump".
7.10.2. Pressure sensor
From the menu bar select System > Service > Adjustment > Pressure sensor
- Measurement ampliers for steam generator is calibrated
7.10.3.pH-Measurementampliers
From the menu bar select System > Service > Adjustment > pH-Measurement
ampliers
- The pH-measurement ampliers are calibrated
7.10.4. Firmware Update
From the menu bar select System > Service > Firmware Update
- Vapodest Firmware is updated
7.10.5. Check the in- and outlets
From the menu bar select System > Service > Adjustment > Check in-& out-
lets
- The inlets and outlets are checked.
7.10.6 Statistics data
From the menu bar select System > Service > Statistics
Here you can call up details of the statistics of the instrument:
- Entire running time of instrument
- Total of turning on and off
- Last service
- Next service due on
