Vapodest 50s carousel
14 Tubing diagram
14.1.1. Description of the tubing diagram
Pos. Description Item-No.
1 Diaphragm pump NaOH 1001738
2 Diaphragm pump H
3
BO
3
1001736
3 Diaphragm pump H
2
O steam generator 1001736
4 Diaphragm pump H
2
O sample 1001736
5 Peristaltic pump suction waste 1000084
6 Peristaltic pump suction receiver 1000084
7 Verprene-tubing 4/8 1000498
8 Verprene-tubing 4/8 1000498
9 Tubing reduction, PP 51 x 10 x 5 1000398
10 PTFE-tube suction for titration liquid
1,6 x 3,2 x 1600 mm incl. tting 1001724
11 PTFE-tube with stretched point for titration acid
1,6 x 3,2 x 500 mm incl. tting 1001672
12 Micro dosing pump 1001650
13 Silicon tubing 8 x 16, Outlet condenser 1000497
14 Verprene-tubing 8 x 12 1000499
15 Verprene-tubing 4 x 8 1000498
16 Silicone-tubing 4 x 7 1000488
17 Ventilation glass 1000048
18 Pinch-solenoid valve, shut-off 1000090
19 Pinch-solenoid valve, steam 1000090
20 Novoprene-tubing 4,8 x 8 1002289
21 Tubing reduction 1000397
22 Silicone-tubing 6 x 10 1000484
23 PP-distributor with PP-thread 1000538
24 PTFE-Inlet tubing, NaOH 1003401
25 Silicone tubing 4 x 7 1000488
26 Water inlet tubing 10 x 17 1000394
27 Silicone-tubing 4 x 7 1000488
28 Silicone-tubing 8 x 16 for cooling water outlet 1000497
29 Verprene-tubing 4 x 1000498
30 Verprene-tubing 4 x 8 1000498
When you order additional tubing, please make sure to also give the desired
length!
