Vapodest 50s carousel
4.4.1. Description rear view Vapodest upper part
1 Diaphragm pump for H
3
BO
3
, Item-No. 1001736
Connection pipe for PVC-tubing 4/7, connection to the storage tank "H
3
BO
3
"
2 Diaphragm pump for H
2
O Probe, item-No. 1001736
Connection pipe for PVC-tubing 4/7, connection to the storage tank "H
2
O".
3 Diaphragm pump for H
2
O Dampferzeuger, Item-No. 1001736
Connection pipe for PVC-tubing 4/7, connection to the storage tank "H
2
O".
4 Inlet and outlet tubings for titration acid
Bubbles must be avoided under any circumstances in the inlet tubings in or-
der to guarantee precise titration results (also see instructions in Chapter 7.7.
Rinsing dosing pump).
 5 Microdosingpump(Deviationofowrate<0,2%),Item-No.1001650
Micro dosing pump made of chemically inert ceramic components.
 6 Boxformicrodosingpump
Protection for micro dosing pump
7 Level detector
Connector for diode plug, 3-pin (level detector for external storage tanks)
8 Appliance plug for mains cable
The enclosed mains cable is plugged in here
9 Excess current switch, 10A
Equipment is cut off automatically if there is excess current
10 InterfaceRS485,ComBox
Connection for data cable RS-485 ComBox.
11 Interface RS 485,
12 Outlet ventilation tubing (protected)
Ventilation for steam generator, here hot steam can escape
13 Excess pressure - steam outlet
Safety device to let steam escape in case of overpressure in the boiler.
14 Excess temperature fuse
Safety measurement to turn off heating if the water level in the steam generator
drops so low that the heating cartridge is not covered any more. See also eror
message in chapter 12. 1 "NO H
2
O FOR STEAM GENERATOR".
15 Identicationplatewithserialnumberoftheinstrument
Please make sure to always refer to the serial number in any case of service
problem.
16 Cooling water inlet with sieve, Item-No. 1000363
Connection thread ¾ inch for water inlet tubing 10/17
17 Water outlet
Connection pipe for PVC-tubing 8/12, connection to water outlet
18 Peristaltic pump for receiver, Item-No. 1000084
Connection pipe for PVC-tubing 8/12, connection to water outlet
19 Peristaltic pump for sample suction, Item-No. 1000084
Connection pipe for Verprene-tubing 8/12, connection to store tank "Sample
waste".
20 Diaphragm pump for NaOH, Item-No. 1001738
Connection pipe for PVC-tubing 8/12, connection to storage tank "NaOH"
4 Description of the equipment
